Suzuki LT-Z 400 Quadsport Special Edition 2 WD [2008-2012] - connecting rod set

HOT RODS connecting rod set for Suzuki LT-Z 400 Quadsport

This connecting rod set from HOT RODS is intended for the Suzuki LT-Z 400 Quadsport Special Edition 2 WD from the years 2008-2012. The assignment refers to the special edition version mentioned with 2 WD and a 4-stroke engine. This allows the vehicle variant and year of manufacture to be clearly compared before selection.

Function and execution

The sentence summarizes the coordinated components of the connecting rod area. In addition to the connecting rod, a crank pin and the associated crank pin bearing are included in the scope of delivery. The specified diameters, widths and lengths enable a precise comparison of the relevant dimensions.

Technical data

• Engine type: 4-stroke
• Inner diameter of the large connecting rod eye: 43 mm
• Width at large connecting rod end: 21,800 mm
• Center-to-center length of connecting rod: 107 mm
• Inner Ø of the small connecting rod eye: 20 mm
• Width at the small connecting rod end: 20 mm
• Length of the crank pin: 61,800 mm

Included components

• connecting rod
• crank pin
• crank pin bearing

Vehicle assignment

The HOT RODS connecting rod set is exclusively assigned to the Suzuki LT-Z 400 Quadsport Special Edition 2 WD with the complete model year range 2008-2012. Model name, drive variant and year of manufacture should be taken into account together when selecting the product.

Factual selection information

For the technical comparison, the inner Ø of 43 mm on the large connecting rod eye, the center-to-center length of 107 mm and the inner Ø of 20 mm on the small connecting rod eye are particularly important. In addition, the respective widths and the crank pin length are available for comparison.
